Z20 IP68 Waterproof 12.1″ Industrial Touch Panel PC

  • IP68 Waterproof, Dust and Water Resistant, Aviation Head Connector
  • J1900 CPU, Powerful and Energy-Efficient, Intel SOC Chipset
  • AMI Bios, Watchdog Timer, Secure and Stable Operation
  • Mini PCIE for WiFi/4G, with Sim Slot, Expandable Wireless Communication
  • LED Display, 1024 x 768, 350 Lumens, 800 Contrast, 20,000 Hours Backlight
  • Aluminum Alloy Case,326 x 261 x 46.5mm, 4.5Kgs, Durable and Compact
  • VESA Screw Hole for Flexible Installation, Embedded, Wall-Mounted, Desktop, Cantilevered.

Share to:



Experience rugged reliability with our IP68 waterproof 12.1″ industrial touch panel PC. Featuring an aluminum alloy design, it’s suitable for diverse installations and comes with a resistive touch screen, Intel Celeron processor, ample memory, and a fanless cooling system. Ideal for Windows 10 and Linux use, it offers flexible connectivity options and operates flawlessly in a wide temperature range. Rely on this durable solution for various industrial applications, backed by CE, FCC, and ROHS certification




Waterproof Level Fully IP68, full interface waterproof aviation head connector
Material Aluminum alloy
Colour Black
Opening Hole Size 312 x 247mm (L x W)
Size 326 x 261 x 46.5mm
Weight 4.5Kgs
Installation Method Standard VESA screw hole (75 x 75 or 100 x 100mm) for flexible installation, vesa mount for optional
Embedded (recommended)/wall-mounted/desktop/cantilevered etc
Display Type Industrial grade 12.1 inch LED
Resolution 1024 x 768
Lumens (cd/m2) 350
Contrast 800
Touch Type Original imported resistive touch screen
Durability (Number of Touches) >35 million times
CPU Intel® Celeron® Processor J1900 (2M Cache, up to 2.42 GHz)
Chipset Intel SOC
Watchdog Timer 255 levels
Network Card 2 x Realtek 8111E gigabit lan
WiFi and Bluetooth N/A, optional to add
Memory 4GB/8GB RAM
Storage 128G SSD
Expand 1 x Mini PCIE for WiFi/4G, with sim slot
Rear Panel 2 x COM RS232
1 x RS485
2 x Lan
3 x USB2.0
Bios AMI bios
System Support Windows 10, linux ubuntu etc
Cooling Mode Fanless
Power Supply DC100-240V AC/50-60Hz, DC 12V 4A for testing
Packing List PW18  industrial touch panel pc, testing power supply, testing power cord, touch pen, aviation heads, warranty card
Operating Temperature -20℃~60℃ surface air flow
Storage Temperature -30℃~70℃
Working Humidity No request
Certification CE  FCC ROHS

Get quote

If you have any question or inquiry, please don’t hesitate to contact us.


Model Processor Cooling System Graphics Frequency Memory Storage LAN USB COM RS485 Power
Z20 J1900 Fanless Intel® HD Graphics 2.0~2.42 GHz 4GB 128G SSD 2 3 2 1 12V/4A
Z20 J1900 Fanless Intel® HD Graphics 2.0~2.42 GHz 8GB 128G SSD 2 3 2 1 12V/4A
