Overview
The B12 Mini PC is a powerhouse featuring Intel Core i7/i9 processors, up to 64GB RAM, and dual M.2 storage options. With dual-antenna Wi-Fi, smart silent fan cooling, and versatile connectivity, it’s perfect for demanding applications. Compact, efficient, and certified for quality. Ideal for a wide range of uses, from professional to entertainment.
Specifications
| Material | Aluminum alloy |
| Colour | Silver |
| Size | 160 x 150 x 57mm |
| Weight | 2Kgs |
| Insallation Method | Desktop type/vesa mounting |
| With holding vertical stand, vesa mount as the optional | |
| CPU | Intel® Core™ i7-8750H Processor (9M Cache, up to 4.10 GHz) |
| Intel® Core™ i9-9880H Processor (16M Cache, up to 4.80 GHz) | |
| Intel® Core™ i7-10870H Processor (16M Cache, up to 5.00 GHz) | |
| Chipset | HM370 |
| Network Card | 1 x Intel RTL 8168/8111/8112 gigabit lan |
| WiFi and Bluetooth | With dual antennas, 802.11ac 2.4+5Ghz, bt 4.0/4.2 |
| Memory | 2 x SODIMM DDR4, up to 64GB RAM |
| Storage | 1 x M.2 2280 (SATA/NVME), 1 x M.2 2280 (NVME) |
| Expand | 1 x M.2 PCIE WiFi slot |
| Front Panel | 1 x Power button |
| 1 x Audio | |
| 1 x Type C | |
| 4 x USB3.0 | |
| Rear Panel | 1 x DC_in |
| 2 x USB3.0 | |
| 1 x Lan | |
| 1 x HDMI | |
| 1 x DP | |
| 2 x WiFi antennas | |
| Bios | AMI bios |
| System Support | Windows 10, linux ubuntu etc |
| Cooling Mode | Smart silent fan (place it vertically to reduce the fan speed & sound effectively) |
| Power Supply | DC100-240V AC/50-60Hz, DC 12V/7A |
| Packing List | B12 mini pc, power supply, power cord, vertical stand, wifi antennas, warranty card |
| Operating Temperature | 0°C~70°C Centigrade (32°F~140°F) |
| Storage Temperature | -20°C~80°C Centigrade (-68°F~176°F) |
| Relative Humidity | 10%~90% (non-condensing) |
| Certification | CE FCC ROHS |
