Overview
Our compact and robust Mini PC, designed with premium aluminum construction, offers versatile installation methods (desktop, wall-mounted, embedded). Powered by various Intel processors, it supports dual monitors with HDMI and VGA ports. Dual RTL8111/8111F Gigabit network ports ensure efficient connectivity. With DDR3/DDR4 memory and mSATA/2.5-inch SSD/HDD storage options, it accommodates diverse user needs. Featuring a range of I/O ports, fanless cooling, and extensive system support, it’s an ideal choice for Windows, Linux, Ubuntu, OpenWrt, ROS, etc. This Mini PC’s reliability extends to its wide operating temperature range, making it suitable for various environments while holding CE, FCC, and ROHS certifications. The package includes the Mini PC, power supply, cord, vesa mount, WiFi antennas, and warranty card, ensuring a comprehensive computing solution.
Specifications
| Material | High-quality all aluminum |
| Colour | Black |
| Size | 136 * 127 * 40 mm |
| Weight | 1.5Kgs |
| Insallation Method | Desktop, wall-mounted, embedded |
| CPU | Intel N2840/J1900/N4000/J4125/3215U/I3 4005U/I3 5005U Processor |
| Display Ports | 1 x HDMI port, 1 x VGA port, supports Connections dual monitors |
| Network Card | 2 x RTL8111/8111F Gigabit network port |
| Memory | 1 x DDR3/DDR4(J4125/N4000 with DDR4) |
| Storage | 1 x mSATA SSD, 1 x 2.5 inch SSD/HDD |
| I/O Ports | 1 x Power Switch |
| 2 x USB3.0 | |
| 2 x USB2.0 | |
| 2 x COM | |
| 1 x Audio | |
| 2 x LAN | |
| 1 x HDMI | |
| 1 x VGA | |
| 1 x DC IN | |
| 2 x WiFi Holes | |
| Bios | AMI EFI BIOS |
| System Support | Support Windows, Linux, Ubuntu, OpenWrt, ROS etc |
| Cooling Mode | Fanless |
| Power Supply | External power 12V 4A DC 5.5*2.5 interface |
| Packing List | Mini pc, power supply, power cord, vesa mount, WiFi antennas, warranty card |
| Operating Temperature | -10°C~60°C |
| Storage Temperature | -20°C~80°C |
| Relative Humidity | 10%~90% non-condensing |
| Certification | CE FCC ROHS |
