Overview
This compact fanless system features 4x Intel 2.5G LAN ports, dual 4K display via HDMI+DP, and flexible storage with M.2 2280 NVMe + SATA III support. Powered by the efficient Intel N100 processor with DDR5 SO-DIMM memory (up to 16GB). Ideal for networking applications with 5G/4G/WiFi expansion and optional COM port. Perfect for firewall/routers (pfSense/OPNsense), digital signage, or industrial use.
Specification
| Processor | Intel n150 Processor 4 Cores 4 Threads |
| B I O S | AMI EFI BIOS |
| Memory slot | 1*DDR5 262PIN SODIMM, up to 16GB |
| Storage slot | 1*M.2_2280 ; 1*SATA3.0 |
| Expansion slots | 1*Mini PCIe Channel for WiFi/Bluetooth/4G; 1*M.2(2230) |
| NIC Model | 4*In-tel i226/i225 2.5Gigabit Network Card |
| Video output | 1*DP port; 1*HD MI port |
| Power supply | DC 12V-4A 5.5*2.5 |
| Included accessories | 1*Power Adapter; 1*Power Plug |
| Certificate | CE、CCC、FCC、ROHS |
