Overview
Introducing the I24 Industrial PC, a robust computing solution crafted from durable aluminum alloy in a sleek black design. Its compact dimensions of 220 x 170 x 55mm and weight of 2.5Kgs make it versatile for various installations, featuring mounting ears for wall-mounted, embedded, or desktop use
Powered by Intel® Core™ i5-1035G1 and i7-1065G7 processors, this industrial PC delivers high-performance computing for a range of applications. The chipset is SOC, ensuring efficient operation.
Connectivity is a breeze with 2 x Intel RTL 8168/8111/8112 gigabit LAN ports, while dual antennas support 802.11ac 2.4+5GHz Wi-Fi and Bluetooth 4.0/4.2.
This industrial PC accommodates up to 64GB of RAM with 2 x SO-DIMM DDR4 slots and offers flexible storage options with a 2.5-inch hard disk bay, mSATA, and M.2 2280 for NVME drives.
Two Mini PCIE slots with a SIM card onboard slot allow for expansion options such as Wi-Fi or 4G modules. The front panel provides easy access to the power button, audio, optical, and USB ports, while the rear panel offers DC-in, HDMI, LAN, USB, COM RS232, and Wi-Fi antennas.
Specifications
| Material | Aluminum alloy |
| Colour | Black |
| Size | 220 x 170 x 55mm |
| Weight | 2.5Kgs |
| Insallation Method | With mounting ears |
| Wall-mounted, embedded, desktop | |
| CPU | Intel® Core™ i5-1035G1 Processor (6M Cache, up to 3.60 GHz) |
| Intel® Core™ i7-1065G7 Processor (8M Cache, up to 3.90 GHz) | |
| Chipset | SOC |
| Network Card | 2 x Intel RTL 8168/8111/8112 gigabit lan |
| WiFi and Bluetooth | With dual antennas, 802.11ac 2.4+5Ghz, bt 4.0/4.2 |
| Memory | 2 x SO-DIMM DDR4, up to 64GB RAM |
| Storage | 1 x 2.5 inch hard disk bay/1 x mSATA/1 x M.2 2280 (NVME) |
| Expansion Slot | 2 x Mini PCIE slot (WiFi/4G), with sim slot onboard |
| Front Panel | 1 x Power button |
| 1 x Audio | |
| 1 x Optical | |
| 2 x USB3.0 | |
| 2 x USB2.0 | |
| Rear Panel | 1 x DC_in |
| 2 x HDMI | |
| 2 x Lan | |
| 2 x USB3.0 | |
| 2 x USB2.0 | |
| 2 x COM RS232 | |
| 2 x WiFi antennas | |
| Bios | AMI bios |
| System Support | Windows 10, linux ubuntu etc |
| Cooling Mode | Smart silent fan (place it vertically to reduce the fan speed & sound effectively) |
| Power Supply | DC100-240V AC/50-60Hz, DC 12V/5A |
| Packing List | I24 industrial pc, power supply, power cord, wifi antennas, warranty card |
| Operating Temperature | 0°C~70°C Centigrade (32°F~140°F) |
| Storage Temperature | 0°C~80°C Centigrade (-68°F~176°F) |
| Relative Humidity | 10%~90% (non-condensing) |
| Certification | CE FCC ROHS |
