B10 Compact High-Performance Mini PC

  • Intel i7, Dual 4K, Versatile Connectivity
  • i7 Processor, 64GB RAM, Multi-Display Support
  • Ideal for Demanding Applications
  • Desktop, Wall-Mount, Embedded Installations
  • Smart Silent Fan for Efficient Operation
  • USB-C, HDMI, LAN, Expandable Storage Options

Share to:



Discover the ultimate computing experience with our sleek, high-quality all-aluminum Mini PC. This compact powerhouse, measuring just 110 x 110 x 36mm and weighing 1.5Kgs, supports versatile desktop, wall-mounted, or embedded installations. Powered by an Intel Core i7-1185G7 Processor with up to 4.80 GHz speed, it’s designed for peak performance. Enjoy stunning visuals on dual monitors through HDMI and VGA ports, complemented by robust memory up to 64GB RAM and dual storage options (M.2 SATA SSD & NVME PCIE3.0 x4 SSD). With a variety of I/O ports, smart silent fan cooling, and support for Windows 10/11 and Linux Ubuntu, this Mini PC is perfect for both professional and personal use. Operating efficiently in diverse environments, it’s certified with CE, FCC, and ROHS, guaranteeing quality and reliability.




Material High-quality all aluminum
Colour Silver
Size 110 x 110 x 36mm
Weight 1.5Kgs
Insallation Method Desktop, wall-mounted, embedded
CPU Intel Core i7-1185G7 Processor 12M Cache, up to 4.80 GHz
Display Ports 1 x HDMI port, 1 x VGA port, supports Connections dual monitors
Network Card RTL8111 10/100/1000 LAN
Audio Card ALC269
Display Port 2 x Full Featured Type-C for charging/data/video/audio, 2 x HDMI2.0b
Memory 2 x SO-DIMM DDR4-3200, max. 64GB RAM
Storage 1 x M.2 2242 SATA SSD, 1 x M.2 2280 NVME PCIE3.0 x4 SSD
Function 1.Support diskless boot
2.Support Restore AC Power Loss
3.Support 4 x display for simultaneous display or synchronous different display, 2 x HDMI, 2 x Type-C
4.HDMI 2.0b 4K: 4096×2304@60Hz
5.Type-C 4K: 3824 x 2160
I/O Ports 1 x SW
1 x Audio
2 x USB3.0
1 x DC_IN
2 x Full Featured Type-C for charging/data/video/audio
2 x HDMI2.0b
1 x LAN
2 x USB2.0
System Support Support Windows 10/11, Linux Ubuntu etc
Cooling Mode Smart silent fan, place it vertically to reduce the fan speed & sound effectively
Power Supply DC100-240V AC/50-60Hz, DC 12V7A, support TypeC PD protocol power supply
Packing List Mini pc, power supply, power cord, WiFi antennas, warranty card
Operating Temperature 0C~70C
Storage Temperature -20C~80C
Relative Humidity 10%~90% non-condensing
Certification CE FCC ROHS

Get quote

If you have any question or inquiry, please don’t hesitate to contact us.

Model Processor Graphic Frequency Display Memory Storage LAN USB Power
B10 I7 1185G7 Intel® Iris Xe Graphics 3.00~4.80 GHz 2 x HDMI2.0b

2 x Type-C 4K

2 x DDR4 RAM 1 x M.2 2242 SATA SSD, 1 x M.2 2280 NVME PCIE3.0 x4 SSD 1 4 DC 12V
