Overview
Compact 1U rack-mounted server powered by Intel Atom C3000 processors (C3758/C3808/C3958) with AES-NI support. Features 10x LAN ports (2x1GbE + 4x1GbE + 4×2.5GbE) and 4x SFP+ optical ports (X553) for high-speed connectivity. Supports 64GB DDR4 RAM, NVMe/SATA storage, and expansion slots (Mini PCIe/M.2/PCIe x8). Ideal for pfSense/OPNsense firewalls with silent cooling and 1U rack design.
Specification
| Model Number | Partaker R13 |
| CPU | Intel Atom C3758/C3808/C3958 Processor |
| BIOS | AMI BIOS (Legacy or UEFI) |
| AES-NI Supported | Yes |
| Memory | 2 x SODIMM DDR4 2400 MT/s, MAX.64GB RAM |
| Storage | 1 x M.2 2280 NVME PCIE3.0 x2 SSD, 1 x 2.5 Inch SATA SSD/HDD |
| Network Card | 2 x Intel I211 1GbE LAN, 4 x I350 1GbE LAN, 4 x I225-V 2.5GbE LAN, 4 x SFP+ Optical, the SFP+ model is X553 |
| Display Port | 1*VGA port (Aspeed BMC chip) |
| I/O | Console, USB2.0, USB3.0, 10 x LAN, 4 x SFP+ Optical, AST 2400 VGA, Power Switch, AC Socket |
| Expansion | 1 x Mini PCIE slot for WiFi/4G, 1 x M.2 3052 USB3.0 x1 signal slot for WiFi/4G, with SIM slot, 1 x PCIe x8 slot |
| Chassis | 1U 19 inch cabinet, rackable, with mounting bracket ears, wall hanging, foot pad |
| Power | 100-240V1.0A, 12V6.25A |
| Cooling System | The processor uses the ball silent cooling fan to ensure the long time work and stable cooling |
| Size | 484 x 252 x 48mm |
| Packing List | Firewall appliance, rackable ears, power cord, warranty card |
| Function | Supports hardware auto power on enabled default, Scheduled boot, Wake-up on LAN, PXE boot, Watchdog |
| System Compatibility | 5.10.x and above core-based freebsd router systems, linux distros, or win.os supported |
| Compatibility | Firewalls for pfsense, opnsense and other popular open-source software solutions |
